Radio install-power wire

[GPG]

Howdy, is there a harness tied up somewhere under the dash ready to power up a radio by chance?

Thanks
GPG



[Colderweather86]

Flipping through the electrical manual, I don't see anything dedicated. I'm betting that's what the Rox Power add on it for.



[Roxasuras]

None that I'm aware of. I ran my to ignition and put a fuse on it.



[GPG]

Howdy 86

I bet that is right I did get a add on fuse block from Amazon that I will go ahead with. I see several of the in dash switch blanks have a harness hooked to the back so thought there may be a chance someone had encountered a ready to go wire for radio. thanks for the feedback I will carry on with my add on block.



[Max A.]

Do you have any factory switch’s like for a light bar? They will have a keyed power source.


Sent from my iPad using Tapatalk



[GPG]

I'm not sure what they are all intended to be for.



[Woodsman74881]

If you just want a quick hot to tie into, you can tie into your power point wire.



[Bister]

If you just want a quick hot to tie into, you can tie into your power point wire.

That's the wire I used to trip the relay to power my extra fuse block that is then powered direct from the battery. The whole thing shuts down with the key.



[Woodsman74881]

That’s what I did with mine as well. If you don’t care about an auxiliary. That wire is easily accessible to hook up 1 item and be fused.



[GPG]

Okay might be a dumb question here but where is the PowerPoint connection?



[Bister]

Okay might be a dumb question here but where is the PowerPoint connection?

The 12 volt power point on the dash on the passenger side. That's the wire we just tied into.



[GPG]

Oh got it for some reason I couldn't get PowerPoint and power port tamasha in my head this morning.



[Woodsman74881]

In days of old, before PC took over, and we were more free, we called it a cigarette lighter. ?



[Roxasuras]

In days of old, before PC took over, and we were more free, we called it a cigarette lighter. ?

Lol, yes



[Bister]

In days of old, before PC took over, and we were more free, we called it a cigarette lighter. ?

Trouble is that they don't work for a cigarette lighters anymore, kids don't know what they are missing. ?



[Roxasuras]

I remember when it used to pop out when it was hot, looking back what a fire hazard.



[Woodsman74881]

But could be quite fun at times.



[Spanky]

In days of old, before PC took over, and we were more free, we called it a cigarette lighter. ?

SMOKE'EM IF YOU GOT'EM!!!!
